Crowne Slate Designer Shingles
Crowne Slate Designer Shingles
Luxurious looks meet quality in Crowne Slate™ shingles. That’s because they mimic the high-end appeal of natural slate tiles while offering 10” exposure and premium asphalt for ultimate protection. Heavy-duty construction cushions the impact of hail and other extreme weather, giving Crowne Slate shingles their Class 4* impact resistance rating — the highest available. Need even more features? Crowne Slate shingles come in four elegant color blends.
Color / Finish:
Luxurious looks meet quality in Crowne Slate™ shingles. That’s because they mimic the high-end appeal of natural slate tiles while offering 10” exposure and premium asphalt for ultimate protection. Heavy-duty construction cushions the impact of hail and other extreme weather, giving Crowne Slate shingles their Class 4* impact resistance rating — the highest available. Need even more features? Crowne Slate shingles come in four elegant color blends.
The Performance Designer Collection
There’s no need to compromise protection for beauty. IKO’s Performance Designer line is built for quality and class in three amazing shingles. Whether you’re boosting curb appeal or blending with your home’s architectural beauty, IKO’s Crowne Slate, Armourshake, and Royal Estate lines offer performance and polish with the assurance of Impact Resistance*.
Specifications & Standards
Standards
-
ASTM D3462
-
ASTM D3018
-
ASTM D3161 Class F
-
ASTM D7158 Class H
-
ASTM E108/UL 790 Class A
-
CSA A123.5
-
FM 4473 Class 4
-
Miami-Dade Approved 3
-
Florida Building Code High-Velocity Hurricane Zone (HVAZ) Approval 3
Specifications
-
Size
39 ½ inches x 13 ¼ inches (1,003 mm x 336 mm)
-
Exposure
10 inches (254 mm)
-
Coverage Per Package
25 sq. ft. (2.32 sq. m)
-
Qty Per Pallet
60 bundles
-
Shingles Per Square
40
-
Quantity Per Unit/Package
10 shingles
-
Warranty Term
Limited Lifetime 1
-
Limited Wind Warranty
130 mph (210 km/h) 1, 2
-
Fire Resistance Rating
Class A
-
Impact Resistance Rating
Class 4 *
-
Iron Clad® Protection Period
15 years 1
1. See Limited Warranty at IKO.com for complete terms, conditions, restrictions and application requirements. Shingles must be applied in accordance with application instructions and local building code requirements.
“Lifetime” means the period of time commencing on the date of the completion of the installation of the shingles on the building and continuing so long as the owner owns the building on which the shingles were installed.
2. High Wind Application is required.
3. Products with Miami Dade NOA, Florida Product Approval, and Texas Department of Insurance listings are available. Miami-Dade & Florida Building Code High-Velocity Hurricane Zone (HVAZ) approvals apply only to shingles available in the southeast US market. For more information please visit: our listings page or contact IKO at: 1-888-IKO-ROOF (1-888-456-7663)
* This rating is solely for the purpose of enabling residential property owners to obtain a reduction in their residential insurance premium, if available. This is not a guarantee of impact resistance against hail. Damage from hail is not covered under the limited warranty.
Note: All values shown are approximate. Product is developed with reference to these Standards. IKO® strives to accurately reproduce the screen images of the shingle swatches and house photos shown. However due to manufacturing variances, the limitations of your monitor resolution, and the variation in natural exterior lighting, actual colors may vary from the images you see. To ensure complete satisfaction, please make your final color selection from several full-size shingles and view a sample of the product installed on a home. Algae-Resistant – this article contains an algae-resistant granule that helps inhibit discoloration caused by blue-green algae.
